Dimensions & specifications
A Armrest width – internal: 450mmB Seat back height: 400mmC Footrest to seat height: 430/460/490/520mmD Minimum footrest height: 131-145, depending on inclination
E Folded footrest depth: 320mm
F Open footrest depth: 530mm
*Maximum staircase angle with a hinge rail: 48 degrees
G Minimum distance from wall to seat back: 60mm H Seat depth: 390mm I Swivel radius: 645mm (625mm with the shorter arm) J Minimum track intrusion into staircase: 200mm
Maximum weight limit: 140kg *Speed: 0.08 m/sec Power supply: 2x12V batteries Staircase angle: 27˚- 55˚
Powered folding footrest
LED diagnostic display
Powered seat swivel
Obstruction sensors
Seat swivel handle
Overspeed brake
Rail extension brackets
Seat swivel locking system
Emergency stop button
Non-slip footrest
Shorter armrests
Retractable seatbelt
Manual hinge rail
One Touch Alert
Velcro seatbelt
